Digital Hydraulic Pressure Gauge,0.4%FS Accuracy,3-1/8" Dial, Industrial Precision Water Liquid Gas Fuel Manometer with Temperature Diaphragm (0-100KPa, NPT1/4)
Product details
| Management number | 210907694 | Release Date | 2026/04/04 | List Price | $35.60 | Model Number | 210907694 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Digital pressure gauge Description:Dial size : 3-1/8" dial (80mm)Pressure Range : -0.1…0.01~100MPaOverload Capacity : 200%Accuracy : 0.4%FS / 0.2%FS / 0.1%FS (This link is for 0.4%Accuracy)Tempe. Accuracy: ± 2 ℃Process connection : G1/2, G1/4, NPT1/2, NPT1/4, M20×1.5mm Connection.Input Voltage : 3V (Two 1.5V AAA batteries) Batteries no included.Working temperature : -4 to 140 deg F/-20 to 60 deg CAmbient temperature: 140 deg F/60 deg C maximumCase : 304 stainless steelCase thickness:1.5mmDiaphragm: 316L stainless steel Case and Connection.Light: LCD Backlight DisplayIP Class : IP65How to operate :ButtonDescription :Powerbutton : ON / OFFUNITbutton : Press the button, cyclicswitching the pressure unit Pressure the "UNIT" botton, Show themaximum minimum value, corresponding to the MAX/MIN logo light up.ZERObutton : Press Zero button for 4seconds, Calibration zeroPeak button：Max/Minpeak value holderFEATURES:Wide pressure range ：-0.1…0.01~100MPaLCD backlight displayFour and a half digitsdisplay Three digits ambient temperature display Zero clearing Max/Min peak value holderPressure progress bar displayBattery indicatorFive pressure unit switching (bar, psi, kPa, MPa, kg / cm2)Notice:1psi=6.895kPa=0.0689476bar =0.006895MPa1MPa=145psi100MPa=14503psi
- 【USE】This Digital Pressure Gauge For hydraulic, oil pressure, water pressure, high pressure, air pressure precision measuring, for media which is not corrosive to stainless steel wetted parts.
- 【ACCURACY】This type digital pressure gauge is 0.4%FS, 0.2%FS, 0.1%FS, Accuracy. This link is for 0.4% Accuracy.
- 【LOWER MOUNT】We can provide 5 specifications G1/2, G1/4, NPT1/2, NPT1/4, M20×1.5mm Stainless steel Connection.
- 【Measurement range】Pressure Range: -0.1…0.01~100MPa, 200% over load. Dial size: 3-1/8", LCD bright backlight. 4 digit display, 5 units, psi, bar, kg/cm2, Mpa, KPa
- 【POWER SUPPLY】Battery Powered . Input Voltage 3V DC, 2 PCS AAA battery（Battery Not Included）
| UPC | 737900053170 |
|---|---|
| Brand Name | TIBROMTACK |
| Manufacturer | TIBROMTACK |
| Material Type | Stainless Steel |
